APFC148-312-90/550V SELEC LCD Type Automatic Power Factor Controller With 12 Relay

Display Type

LCD with Dual Colour Backlight

Display Configuration

3 Lines of 4 Digits to Show Electrical Parameters

Input Type

3-4 Wire, 3-3 Wire, 2-2 Wire, 1-2 Wire

Frequency

45-65 Hz

CT Primary

1/5A to 9999A (Programmable for any Value)

CT Secondary

1 or 5 A (Programmable)

PT Primary

100V to 500kV AC (Programmable for any Value)

PT Secondary

100 to 500V AC (Programmable for any Value)

Accuracy

Power Factor:±0.01, Voltage (L-N/L-L), Current: ±0.5% of full scale,
Frequency  For L-N>20V, For L-L>35V: ±0.1% of full scale,
Power (kW,kVA,kVAr), Energy (kWh,kVAh,kVArh): Class 1, Temperature : ±3° of full scale

Max Number of Steps

12/14* (FAN & ALARM Output Can be Used as 13th and 14th Step)

Communication Protocol

Modbus RTU (RS485 Interface)

Supply Voltage

90 to 550V AC

Bezel Size

144 x 144mm

Mounting Type

Panel Mount
